Full-IP OB Twins Usher in a New Era for Belgium’s RTBF
Mon 06, 07 2020
In early April 2020, RTBF, Belgium’s public broadcaster for the country’s French-speaking community, took delivery of the first of two groundbreaking, full-IP OB trucks. Due to the covid-19 lockdown, the 12m long trailer had to be configured remotely using TeamViewer, a few web cameras and microphones for confirmation purposes as well as via VPN in order to be delivered on time. The second identical OB truck will arrive on 1 July.
Masterminded by Geert Thoelen of NEP Belgium and Dirk Sykora of Lawo, the vehicles built by Broadcast Solutions in Germany will be leased to RTBF for eight years.
The twins come equipped with a 100Gbps Arista-powered network core (audio, video and matrix) that revolves around Lawo’s V__matrix C100 platform for SDI- and IP-based video and audio input/output as well as processing. A Sony XVS-8000 IP vision mixer provides powerful video control for the 16 Sony cameras. The Sony Live System Manager provides the control interface to Lawo’s VSM and NMOS-IS04/05 protocols as required. The LSM allowed Sony to remotely access the Switcher network to configure the IP routing and XVS setups from its engineer’s home during the unfortunate events of covid-19 and pan European lockdowns.
Each truck offers 36 vm_dmv heads delivered by V__matrix C100 blades for multiviewing purposes. Overarching control and orchestration is managed by Lawo’s VSM IP control system.
Both OB trucks support all audio formats (analogue, AES3, MADI with SRC, Dante with SRC and AES67/RAVENNA), which are mixed using a 48-channel-strip mc² 56 audio production console and 512 DSP channels provided by A__UHD Core. Audio and video signals can be sourced from six video stageboxes equipped with V__matrix Silent frames and A__mic8 audio I/O edge devices. In addition, there are eight audio stageboxes containing maxed-out Power Core units as well as two stageboxes with one DALLIS I/O frame each, providing 128dB microphone inputs for exacting audio quality requirements. All of the above run in ST2110.
While reading through the tender documents, Geert Thoelen and Maxime Delobe of NEP Belgium realized that RTBF was expecting highly efficient and future-proof “dream trucks”. Given that an IP backbone had been specified, Thoelen and Delobe suggested basing the two vehicles on ST2110-20 for video and ST2110-30 for audio. In response to a request for Dolby E signal compatibility, Lawo proposed to make all audio streams also available in the ST2110-31 format. “This way, the OB trucks cater to both 24-bit and 32-bit audio needs in any combination: the ST2110-30 or ST2110-31 audio stream versions can be selected at the press of a button on a VSM soft- or hardware panel,” explains Lawo’s Dirk Sykora. “This user-friendly approach eliminates time-consuming and costly system reconfigurations before an upcoming event,” adds Geert Thoelen.
According to Olivier Malevez, Project Manager New IP Outside Broadcast at RTBF, the decision to order two identical OB trucks was partially based on the expected possibility to use them as one giant system for major events when necessary. Used as stand-alone trucks, they cover all applications ranging from compact six-camera assignments to big live concerts and sporting events. Both OB trucks can be docked to RTBF’s broadcast building via SDI or IP: “We also wanted the option of using the two OB trucks as additional control rooms on our premises in peak situations,” explains Jean Vanbraekel, RTBF’s Head of Technology Operations and Distribution.
For Broadcast Solutions in Germany, planning and configuring the 100G Arista network core as well as building and delivering the first full-IP OB truck posed two challenges: equipping it with an SMPTE 2110 fabric and meeting the deadline despite the worldwide covid-19 lockdown, while also carrying out all requested amendments. Underpinning Broadcast Solutions’ approach as a manufacturer-independent SI to plan and deliver the best product in close cooperation with manufacturers and customers was/is also the guideline for the completion of the two RTBF OB vans. Founding on years’ of experience in the construction of OB vans, Broadcast Solutions, in cooperation with NEP/RTBF, was able to make many individual coach building, workflow and detail adjustments, which make the work of the crews much easier and more pleasant. The insights gained from the planning of the duo’s first OB van were directly implemented in the construction of the second, identical one, which is currently being completed in Broadcast Solutions’ production halls and is about to be delivered.
Matthias Hahn, Project Leader at Broadcast Solutions: “Building an IP- and ST2110-based OB truck is still the exception that confirms the rule. By laying a solid IP foundation, the Broadcast Solutions team proved that it was up to this challenging task. I am all the more pleased that our team has laid the foundations for the success of the vehicle by planning the network core and configuring the 100G network in the OB truck. Our constant, close collaboration with manufacturers and customers paid off, especially during the construction and configuration period and during acceptance. With extensive measures in our production halls and many remote sessions, we were able to deliver the OB truck without delay, even under the special conditions caused by the COVID-19 pandemic.”
The experience gained with the first OB truck is now being “copied and pasted” to the second vehicle. Dirk Sykora of Lawo: “Explaining the vast capabilities and flexibility of the V__matrix platform at the onset of the project was highly beneficial for a swift and effective configuration phase. Both HD trucks are 4K/UHD-ready, which—from Lawo’s perspective—is a simple matter of retasking existing C100 blades.”
Sony’s Account Manager Daan Herreman: “Being recognized as a trusted and innovative technology partner for many years to RTBF and NEP Belgium, we were delighted Sony was the preferred choice for this unique IP project. We can fully support the SMPTE ST2110 & AMWA NMOS Series of open standards to provide necessary interoperability for our customers.”
NEP Belgium’s Geert Thoelen: “RTBF’s two new OB trucks are among the most advanced on the planet and reflect the innovative ways in which NEP consistently implements the latest technologies. Building relationships on mutual trust and innovation has always been at the heart of NEP’s activities. RTBF’s ST2110-based approach has resulted in highly flexible tools for OB assignments of any scale.”
Cécile Gonfroid, CIO at RTBF: “We obviously knew that an IP infrastructure was the answer to our current and future needs. NEP Belgium’s guidance was invaluable, and their proposals were based on what ultimately provided the highest benefit for RTBF. We consider our two full-IP OB trucks the first building blocks of our future Media Square facility.”
RTBF is the Belgian radio and television of the Wallonia-Brussels Federation, an autonomous public enterprise of a cultural nature. Active in television, radio, the web and social networks, RTBF acts as a global media player and the engine of expression and fulfilment of its audiences of today and tomorrow. As a public service media, its mission is to guarantee pluralist and independent information to the French-speaking community of Belgium (approx. 4.5 million people), but also to promote culture, heritage and talents and to ensure the transmission of memory. Its mission is to entertain, educate or even contribute to social cohesion and the development of local economies.
About NEP Belgium
NEP Belgium provides the technology, expertise and global network to help its clients deliver amazing productions. We offer a full range of industry-leading solutions for broadcast and live events, as well as a complete range of media solutions to manage your content. When the world’s premier broadcasters need flawless delivery, they turn to NEP for the solution. For more information about these new OB trucks, please visit www.nepbelgium.be.
Lawo designs and manufactures pioneering network, control, audio and video technology for broadcast and post production as well as live performance and theater applications. All Lawo products are developed in Germany and manufactured to the highest quality standards at the company’s headquarters in the Rhine-Valley town of Rastatt, Germany. For additional information, please visit www.lawo.com.
About Broadcast Solutions
Headquartered out of Bingen, Germany, Broadcast Solutions is one of the leading media technology and system integration companies in Europe, the Middle-East and Africa. It specialises in mobile, fixed and hybrid installations for broadcasters, production houses, enterprise and government organisations.
Established over fifteen years ago, Broadcast Solutions is a privately held company with offices throughout Germany as well as in the UK, Scandinavia, Ukraine, Russia, the United Arab Emirates and Singapore.
Sony Professional Solutions is part of Sony Corporation and exists to help professionals to truly live their vision, by unleashing the incredible power of images. With a winning combination of innovative technology and industry expertise, Sony partners with businesses across a wide variety of sectors including Media and Broadcast, Sports, Healthcare, Corporate, Education and Theatre to deliver industry leading and transformational customer solutions. Operating with over 40 years’ experience and a trusted network of established technology partners, the wide Sony portfolio of knowledge, products and services propositions provides true value to businesses and informs, educates and inspires their customers.
