HD BROADCAST Chooses Leader LV5600 Waveform Monitors for OB2 UHD Truck
Fri 26, 06 2020
Nieder-Olm, Germany – June 24th, 2020 – Television production service provider HD BROADCAST has invested in Leader LV5600 waveform monitors for installation in its new UHD OB2 outside broadcast production vehicle. The instruments will be used to ensure precise matching of incoming signal feeds and to maintain the highest possible video and audio signal quality through to the transmitted output. Six units were supplied by Leader Europe distribution partner LOGIC Media Solutions.
“UHD gives content producers the ability to deliver a level of picture quality akin to the real-world live experience,” says HD BROADCAST MD Constantin Novotny. “The initial challenge production teams face is to ensure every camera is fully aligned and matched to any others being used, not least in terms of colour temperature. Using the LV5600 instruments we can check those parameters quickly and accurately both in terms of signal levels and chroma vectors.”
“Each LV5600 also includes a very useful tool for checking that the captured image is in perfect focus. This is especially valuable given the tremendous amount of detail UHD can resolve. The instruments also provide the measurement capabilities needed to handle additional parameters such as high dynamic range and wide color gamut. Being able to view multiple waveforms on the internal display screen or port these out to an external monitor is another very useful feature. Space-saving is also important issue. Each unit is highly compact which is appreciated even in the largest OB trucks.”
“We are seeing a continuing upward transition from HD as a production format, especially in the sports category where spectators appreciate the high degree of realism UHD has to offer,” adds LOGIC Media Solutions MD Christophe Bingemer. “The LV5600 waveform monitor and its equivalent rasterizer have become the logical choice for many studio-based and OB service providers operating within the SDI, SDI/IP hybrid and purely IP domains.”
Leader’s LV5600 is a mains-powered SDI/IP waveform monitor in a half-rack width 3U desktop chassis with a touch-screen front panel display. It provides all the facilities needed to monitor UHD/HD/SD-SDI and video-over-IP seamlessly in a hybrid operating environment. Engineering related features include test pattern generation, eye pattern display, closed caption monitoring, CIE color chart, high dynamic range measurement, focus assist, customisable screen layout, tally interface, 4K/UHD operation, 10G IP input and 12G-SDI interfaces. SMPTE 2022-6, SMPTE 2022-7 and SMPTE 2110 protocols are all supported. The LV5600 also incorporates Leader’s intuitive Cinezone and Cinelite which are familiar to many content production staff.
HD BROADCAST’s UHD-2 OB truck is a 16.5 meter triple expanding trailer designed for live outdoor broadcasting and studio-support. The vehicle is configured into four separate control galleries and can accommodate up to 28 production personnel. Production facilities include up to 30 UHD cameras, five UHD HDR shader desks, 2 Sony vision switchers, EVS real-time and slow-motion instant-replay and Lawo audio control.
About HD BROADCAST
Based at Nieder-Olm near Mainz, HD BROADCAST (www.hd-broadcast.de) offers mobile production and recording services to clients in subject areas such as sports, concerts and general entertainment.
About LOGIC Media Solutions
Operating from headquarters in Bickenbach and additional premises in Mainz, LOGIC Media Solutions (www.logicmedia.de) provides a wide range of services for virtually all German broadcasters, telecommunications companies and leading production houses. Its goal is to be a one-stop shop, configuring and installing devices according to customers’ wishes. On request, LOGIC Media Solutions will create a detailed specification of a customer’s requirements and supervise the installation or implement the configuration.
About Leader Electronics Corporation
Leader Electronics Corporation (www.leader.co.jp/en) has earned a worldwide reputation for designing and manufacturing highly reliable, practical and cost-effective test and measurement instruments. Leader products are specified for research, development, broadcast, production and service applications. Manufacturing quality is built in every step of the way. Less than 0.1% of all Leader products made are ever returned for warranty repair or adjustment.
The Leader product range includes award-winning 3G/HD/SD SDI waveform monitors and rasterising test instruments with customisable layout. Among available options are 4K/UHD, CIE color chart, HDR measurement, test pattern generation, eye and jitter measurement and closed caption display, IP and 12G-SDI. Leader has helped many customers manage their transition from analog to digital, from SD to HD, from HD to 4K/UHD, from SDR to HDR and from BT.709 to BT.2020 wide color gamut. Leader also provides dependable support for the transition from SDI to IP.
