All twelve channels are demodulated simultaneously, allowing you to monitor a complete network in real time.
- Next generation of the DTA-2139C with added support for ATSC 3.0 and ATSC 1.0 (8VSB). Combinations are supported, too!
- Twelve tuners and demodulators, each tuneable to any frequency in the VHF or UHF band, and each outputting the entire stream.
- Each receiver provides an indication of lock status, RF level and MER for that channel.
- 24/7 continuous compliancy monitoring of an entire cable or terrestrial network, using DekTec Xpect or another monitoring solution.
- Receiving all (or many) services in a free-to-air terrestrial network and remultiplexing them to a cable network.
- Creating a mosaic of all services on a cable or terrestrial network.
Other products from this company:
4T2 Content analyser
All standard all band portable modulator...
Chimera-RM Professional Video Encoder / Satellite...
Falcon HMR
StreamXpert
StreamXpert
Twelve-channel cable/terrestrial receiver for PCIe
4T2 Content analyser
The 4T2 Content-Analyser supports DVB, ATSC, ISDB, and DVB T2-MI extensions.
- Terrestrial DVB-T/T2, Satellite DVB-S/S2, ASI, IP and file input.
- Analysis of DVB-T MIP Megaframe Initialisation Packets.
- Visualisation of PID Packet Identifiers, associated bit-rates, and packet stuffing.
- Raw data analysis with smart trigger function allows the unattended checking of streams for specified fault conditions.
- Smart Packet trigger with expression editor.
- Visualisation of repetition intervals of tables as defined in TR.101.290.
- TR.101.290 analysis and visualisation of first, second, and third priority Errors.
- Measurement of PCR Program Clock Reference repetition, jitter, and Delta.
- DVB-Teletext & DVB-Subtitles display.
- Multi-Viewer content decoding, including H.264 and H.265 material.
- Loudness measurement for each audio services.
- Black/freeze detection on services in the transport stream.
- Detection of audio mute condition on services in the transport stream.
- Comprehensive logging features with powerful sorting capabilities.
- Saving of Transport Stream to disk in presence of errors (with a pre and post buffer).
- Multiple instances of the program can run at the same time, supporting multiple inputs at the same time.
All standard all band portable modulator for USB-3
- General-purpose test modulator in your R&D lab for developing, qualifying or repairing any equipment with an antenna input.
- Portable demo set for TV receivers, easy to carry to customer demos, trade shows, etc.
- TV distribution using modulated signals in shops, hotels, hospitals etc.
- Supports all constellations and modulation modes for each supported standard.
- Excellent signal quality through direct digital synthesis of the RF output signal.
- No power supply required: A single USB-3 connection supplies power, real-time data and control.
The DTU-315 reads data from USB and forwards it to a baseband modulator, a channel filter, an optional channel simulator and an upconverter. The digital RF signal is converted to analogue with a high-speed D-to-A converter and output on a micro-BNC connector.
Chimera-RM Professional Video Encoder / Satellite Modulator
CX-4
CX-4 Transport stream converter.
The CX-4 is a flexible 1U unit containing four independent transport stream converters, each of which can be user configured to convert between Transport Streams over IP to Asynchronous Serial Interface (TSoIP to ASI) or Asynchronous Serial Interface to Transport Streams over IP (ASI to IP). This flexibility ensures your capital costs to a minimum as you can be sure you always have the correct converter to hand.
Complying with both the DVB and SMPTE2022 standards the TSoIP interface supports Transport stream encapsulation, forward error correction and UDP/RTP de-encapsulation as defined by the SMPTE 2022 specification. Hence allowing you to match the resilience of your stream to the performance of your network.
This professional product is designed for easy and reliable operation. It is controlled via a GUI using the onboard web server which is on a separate IP interface to the TSoIP signals. The chassis is fitted with dual power supplies and adequate ventilation to ensure for reliable service in the broadcast environment.
For added flexibility the unit can be configure at manufacture with any combination of one to four converters.
Applications: For use in Terrestrial, Cable and Satellite broadcast systems.
Falcon HMR
The Falcon HMR5440 and Falcon HMR5442 support all common HD and SD video formats. Multiple video output formats are supported including: analog NTSC and PAL, and digital SDI for standard definition; and HD-SDI and component video for high definition. The Falcon HMR5442 adds support for 1080p50/60 3G-HD-SDI and HDMI. Video processing is automatically sensed by the decoder and processed as either MPEG-2 or MPEG-4, SD or HD. Included in the basic functionality of the Falcon HMR5440 is video resolution conversion from HD to SD, and from SD to HD, and aspect ratio conversion from 4:3 to 16:9 and from 16:9 to 4:3.
Both Falcon HMR models decode up to eight audio channels (four pairs) with analog and digital outputs, and embedded within the SDI or HD-SDI video signal.
The Falcon HMR family provides an embedded Web browser, an intuitive front panel interface, or RS-232 command line interface for easy configuration and monitoring.
StreamXpert
- Quickly shows you the contents of OTT, transport streams, ATSC 3.0 etc., and lets you explore metadata in great detail.
- Deep decoding of tables and descriptors with user-customizable templates.
- Integrated video, audio and teletext decoder supporting all industry-standard formats including HEVC and Dolby AC4.
- Test and validation of equipment with transport-stream output, e.g. multiplexers
- Quality monitoring of transport streams in studios, head ends, etc.
- Combine the StreamXpert with a DTU-245 and a notebook to create a truly portable transport-stream analyser
StreamXpert comes in two versions:
- Full (-SX) – All StreamXpert functionality;
- Lite (-SL) – Lower-priced version with decoding and basic recording functions only.
The Full version is an essential tool for all digital-TV professionals that need a fully featured stream analyzer. The Lite version serves as a basic transport-stream viewer and recorder.
Upgrading from StreamXpert Lite to the full StreamXpert is easy. Just contact your local distributor or DekTec for a quote for DTC-320-SX StreamXpert.
- SX – Standard full StreamXpert license (DTC-320-SX)
- SXDGL – StreamXpert license on a USB dongle (DTC-320-SXDGL)
- NIC – StreamXpert license on a USB dongle for local NICs (DTC-320-NIC)
- SL – StreamXpert Lite (DTC-321-SL)
StreamXpert
- Quickly shows you the contents of OTT, transport streams, ATSC 3.0 etc., and lets you explore metadata in great detail.
- Deep decoding of tables and descriptors with user-customizable templates.
- Integrated video, audio and teletext decoder supporting all industry-standard formats including HEVC and Dolby AC4.
- Test and validation of equipment with transport-stream output, e.g. multiplexers
- Quality monitoring of transport streams in studios, head ends, etc.
- Combine the StreamXpert with a DTU-245 and a notebook to create a truly portable transport-stream analyser
StreamXpert comes in two versions:
- Full (-SX) – All StreamXpert functionality;
- Lite (-SL) – Lower-priced version with decoding and basic recording functions only.
The Full version is an essential tool for all digital-TV professionals that need a fully featured stream analyzer. The Lite version serves as a basic transport-stream viewer and recorder.
Upgrading from StreamXpert Lite to the full StreamXpert is easy. Just contact your local distributor or DekTec for a quote for DTC-320-SX StreamXpert.
- SX – Standard full StreamXpert license (DTC-320-SX)
- SXDGL – StreamXpert license on a USB dongle (DTC-320-SXDGL)
- NIC – StreamXpert license on a USB dongle for local NICs (DTC-320-NIC)
- SL – StreamXpert Lite (DTC-321-SL)
Twelve-channel cable/terrestrial receiver for PCIe
- Next generation of the DTA-2139C with added support for ATSC 3.0 and ATSC 1.0 (8VSB). Combinations are supported, too!
- Twelve tuners and demodulators, each tuneable to any frequency in the VHF or UHF band, and each outputting the entire stream.
- Each receiver provides an indication of lock status, RF level and MER for that channel.
- 24/7 continuous compliancy monitoring of an entire cable or terrestrial network, using DekTec Xpect or another monitoring solution.
- Receiving all (or many) services in a free-to-air terrestrial network and remultiplexing them to a cable network.
- Creating a mosaic of all services on a cable or terrestrial network.
';
Related Products:
Oracle Communications Diameter Signaling Router
Monitoring and Control (Satellite related services...
Dalet OnePlay
Actus Advanced OTT Monitoring and Analysis
VPDU
MDU14-CO
InSite
MDU12-PMi
Etere SNMP Console
MediaServicesIQ
MonitorIQ
Dymos(TM) Event Driven Monitoring
All-in-One Compiance Monitoring
ILLUMINATOR
Vela Encompass
Twelve-channel cable/terrestrial receiver for PCIe
BCi Digital Systems Integration
ControlBridge®
DataMiner
Oracle Communications Diameter Signaling Router
Centralize Diameter routing and create a secure signaling architecture that reduces complexity and cost, and enables elastic growth, interoperability, visibility, and rapid introduction of new offerings.
';
Monitoring and Control (Satellite related services & applications)
Dalet OnePlay
An extension of Dalet Galaxy five, Dalet OnePlay not only automates the control of all devices in the studio, it also fully leverages the MAM, NRCS and workflow orchestration capabilities of the platform to open up new forms of audience engagement and revenue opportunities, all the while optimizing the costs of the entire operations
Dalet OnePlay benefits any production of scripted shows, making it an ideal solution for newscasts, sports magazines, live and live-to-tape studio shows.
Modern UI, collaboration and orchestration unleash new opportunities
Dalet OnePlay’s modern, intuitive and efficient UI and UX combined with the agile Dalet Galaxy five News Production and Workflow Orchestration platform enables custom live production workflows with unrivaled operational flexibility, way beyond traditional studio production.
The single shared environment gives way to much smoother and efficient collaboration between show preparation and studio production teams.
More content to more platforms with the same resources
The Dalet Workflow Engine facilitates synchronized multiplatform distribution and automated social media publishing, mitigating operational errors across the board.
This modern workflow allows media organizations to shift their operations forward and get more content to more platforms in a shorter timeframe with the same resources, all while ensuring audiences receive consistent and high-quality experiences across all delivery devices.
Fully Featured and Fully Integrated
Dalet OnePlay controls all device types including video switchers and servers, cameras, audio mixing consoles, graphics, lighting, routers and more. The intuitive, web-based user interface controls all core production devices and is fully integrated with Dalet Galaxy five for seamless workflows, automation and ultra-efficient collaboration between the newsroom and playout.
';
Actus Advanced OTT Monitoring and Analysis
As the global over-the-top (OTT) services market keeps growing, so to does the demand for OTT quality of service and quality of experience monitoring and analysis.The Actus intelligent monitoring platform can combine OTA and OTT analysis on the same platform or can be implemented as an exclusive OTT monitoring solution, supporting any internet-based protocol, such as HLS, RTMP, RTSP, SRT, ZIXI, NDI, MPEG-DASH, Smooth, and others.
Content can be recorded at several points in distribution chain to compare content ant points before and after various CDNs, with alerts sent on any audio and video issues, including low or missing audio, blue screen, black screen, frozen image, pixelization, missing closed caption, and more.
The Actus Alert Center constantly monitors all renditions of OTT streams in real-time, alerting on any technical issue that impacts the viewer’s quality of experience as well as segments where closed captions or SCTE triggers are missing.
Any exception is logged and reported via multiple methods, including e-mail, SNMP, dashboard, multiviewer, log files and popular group-texting applications.
';
VPDU
Building on the success of our horizontal PDUs, used by major broadcasters worldwide, TSL Products introduces a range of vertical power distribution units (VDPUs).
Save Space and Money: The new vertical design utilises unique individually fused IEC Connectors to provide the highest density available, allowing you to save valuable rack space. The design also features low energy consumption for a leaner, greener and more space efficient rack room. The new VPDU has dual 32A inlets, with each inlet powering twenty individually fused C13 outlets.
Features:
- Dual 32A inlets, with each inlet powering twenty individually fused C13 outlets.
- High density means the overall unit is only 1767mm.
- Each Outlet is individually fused and has its own status LED.
- A and B Outlets are easily identfiable through the colour coding of status LEDs.
- Easy mounting from rear on sides for extra flexibility and ease of installation.
';
MDU14-CO
Our Power Management family has been designed to address the challenges faced by systems managers to effectively maintain system viability, control critical power infrastructures – over local or international networks – to meet targets and increase ROI.
Features:
- Dual input seamless auto changeover
- 14 way fused IEC outlets
- Master input setup button with dual tri colour status LEDs
- Input status monitoring GPO on rear D9 connector
- Tri-colour LED input and power indicators
- Rounded cable tie bar
';
InSite
Facilities are generating ever more data, and although this information is readily available from individual devices, it is cumbersome to access and report on when using numerous manufacturer specific portals. Real-time data is hugely beneficial in the daily running of any facility – minimising down-time and decreasing power consumption - as long as it is accessible from a single point where it can be analysed as a whole, rather than having to access and report from individual manufacturer-specific portals.
InSite is a vendor independent solution that brings all of this information together into a single system using industry standard protocols such as SNMP and Modbus.
It can be hosted on premises or in the cloud and will work with a broad range of third party manufacturer of sensor and data centre equipment - in fact any manufacturer who produces object identifier (OID) information.
DID YOU KNOW? InSite can be configured to provide a protected whole system view for central monitoring and individual subsystem viewer for local system monitoring.
';
MDU12-PMi
The MDU12-PMi is a Power manager mains distribution unit, 12 way, 16 x GPIs, ethernet output monitoring and alarms – email and SNMP, individually controlled latching relays, sequential & delay power up with current sense network monitoring
Features:
- Remote Ethernet control of 12 separate outputs via secure web browser
- Overall Status page showing individual & total power consumption
- Power Factor Monitoring
- Sequential, immediate or user configured delayed output startup
- Ethernet input power failure alarm
- Internal temperature sensor with SNMP alarm
- Unit and SNMP configuration via secure web browser interface
- Front Panel LAN status LED
- Tri-colour output status LEDs
- Rounded cable tie bar
- Supplied with Powercon Input connector
- Tri-colour front panel using status LEDs for rapid failure identification
- Intuitive Graphic User Interface (GUI) for ease of set-up
- Self contained operation with all software and hardware functions
';
Etere SNMP Console
Etere SNMP Console is a highly customizable solution that optimizes all processes, infrastructure performance and devices from within a single interface.
Etere SNMP Console is the leading edge technology with a simple, intuitive and user-friendly interface that helps to optimize all the infrastructure performance and availability of a system. The SNMP Console provides a smarter solution since it takes under-control not only Etere solutions but all processes/devices in the system. Etere innovates and upgrades its Console continuously to transform any broadcast system into a completely safe solution because the security is of utmost importance! All processes are monitored by SNMP standard protocol.
Etere provides a common, flexible and easy-to-use browser interface, designed to be highly customizable to facilitate system monitoring, it's able to detect and recover potential problems automatically. Etere SNMP Console is capable to receive SNMP messages sent by other non-Etere applications or devices such as network switches, routers, and firewalls.
Key Features
■Easy monitoring and management of all the system
■Monitors the status of the system and performs diagnostics
■Handshakes Etere applications to check if they are running correctly
■Controls any SNMP enabled process
■Saves the history log of what happened in your system
■Gives you a view of your machine room to easily locate every PC
■Web access console for an easy control of the system
■In order to improve monitoring of devices, modules and workflows, all Etere components are automatically subscribed to SNMP Service, periodic heartbeats are sent via SNMP
■Etere SNMP Console detects missing heartbeats and sends both a visual-alarm and a real-time e-mail notification to the operations department
■Increased visibility to isolate raised faults
■Etere SNMP Console is smartly divided across different panels to allow a quick monitoring of specific functions
■Manage and archive all SNMP messages
';
MediaServicesIQ
Media ServicesIQ provides an easy-to-access portal to cloud-based AI/ML services through custom-developed workflows.
KEY FEATURES & CAPABILITIES
Metadata Generation
Cloud-based collection of speech-to-text and video intelligence applications automating the generation of speech and video-based metadata Provides off-the-shelf integration with the Avid system Easily interfaces with existing workflows using REST API Video intelligence metadata for face, logo, ad, number, on-screen text, object, and shot change detection Metadata with timecodes for tagging, enabling search and faster content retrieval.
Automatic Closed Caption/Subtitle Generation
Machine-generated, time-synced outputs in various sidecar formats for further processing Faster, scalable, reliable, and secure generation of preliminary outputs Easily ingest sidecar files into workflows for repurposing.
CC Quality Conformance for Multi-Platform publishing
Generate reports on non-conformance parameters within a CC sidecar file Automatically compares against predefined style guides standards from platforms such as Netflix Time coded error reports for easy navigation and correction Ability to ingest multiple sidecar formats.
Auto classify content for better value
Automatically create a classification for content Classify advertisements using various labels to automatically identify and ingest Automatic classification of high-points in a feature-length video Easily integrate and ingest labels into existing workflows.
';
MonitorIQ
Equipped with the technological power of AI, Digital Nirvana’s MonitorIQ 7.0 provides new capabilities for compliance logging and monitoring. Known as the industry’s most reliable, secure, and easy-to-use broadcast monitoring and compliance logging platform that allows operators to record, store, monitor, analyze, and repurpose content quickly and efficiently with a minimum of clicks. MonitorIQ enables broadcasters to collect and use knowledge about their broadcast content to meet a wide range of regulatory and compliance requirements. Version 7 of the Digital Nirvana platform gives broadcasters access to valuable next-generation content processing and analysis tools.
';
Dymos(TM) Event Driven Monitoring
Qligent’s Dymos(TM) Monitoring solution packages all of the QoS, QoE and Compliance Monitoring benefits of Qligent’s flagship Vision system for temporary services in the cloud, giving service providers a friendly pricing model and lightweight monitoring infrastructure that turns on and off as needed.
The dynamically-fashioned instance enables the support of events with minimal notice, connecting the service provider’s infrastructure with a Qligent Vision system in the cloud through a secure URL. Customers get the same benefits as 24/7 Vision users, monitoring QoS-related transport and physical streams, QoE-related issues (lack of signal, video freeze, missing audio) and compliance-related matters, such as audio loudness and closed captioning.
The instantly deployable system provides all the same standard Vision components, including aggregation servers and networked probes for gathering performance data across the delivery chain. Measurement and compliance results and recordings are still available for the customer after the event for a defined period of time – with no additional costs associated as the probing cloud instances have been turned off.
';
All-in-One Compiance Monitoring
Qligent Vision Compliance Monitoring system unlocks a centralized portal to monitor the three pillars of quality of service (QoS), quality of experience (QoE) and compliance in one flexibly priced solution.
Qligent has long offered an enterprise-level Vision solution for large TV networks and distributed service entities, covering a broad array of monitoring and analysis requirements across many locations. Qligent’s new All-In-One Compliance Monitoring system is tailored for the local TV stations and smaller station groups tasked with the same responsibilities, including loudness and closed caption monitoring, at a more modest scale.
Perhaps most unique is the inclusion of QoS and QoE monitoring – two core Qligent competencies that are rarely offered in compliance monitoring systems. While TV stations can now cost-efficiently monitor their own QoS-related transport and physical streams along with QoE-related issues (lack of signal, video freeze, missing audio), the system also allows broadcasters to record and monitor live program streams from in-market TV stations. These powerful capabilities will give broadcasters consistent insight into competitive QoE performance, as well as clear evidence of what local businesses are advertising with those stations.
Qligent will supply all software, common off-the-shelf hardware, and QoS/QoE/compliance toolsets as an instantly deployable system, which removes the cost and integration burden of expensive, proprietary compliance systems. The flexible pricing structure offers monthly or annual fees for the same turnkey solution, which provides consecutive days of 24/7 compliance recording through the contracted period. Options to monetize programming, such as content repurposing, are available for additional fees.
';
ILLUMINATOR
Information is your greatest asset. ILLUMINATOR gives access to the key data that is vital to your business performance, presented in a way that is easy to visualise and interpret. Users access data through a client customisable control layer, known as a workspace, which sits on top of the core ILLUMINATOR framework. This allows the software to be tailored to exact client’s needs. The workspace provides users access to any data, whether mastered within ILLUMINATOR’S extensible database, or resident externally in other systems.
ILLUMINATOR allows users to view and manage data from legacy or difficult to maintain datasets, in a single environment. It can consume data in many formats reducing the need for multiple, disparate ‘data islands’ often constructed in spreadsheets, Access or bespoke SQL database solutions.
Work Together
In addition to the user defined Workspaces, the ILLUMINATOR core framework facilitates pre-built or custom functional module plugin capability. Existing modules can be adapted, or new and specially tailored modules can be created with Graphical Data’s support, to ensure you get the solution you need. These functional modules are designed to enhance the power of ILLUMINATOR, improving how users view and work with their data, on a daily basis.
All parts of the business can contribute; suppliers, contractors and customers can also engage if required. Each user has their part to play and every team member's input contributes to overall success. ILLUMINATOR’s communication features allow quick, consistent input and feedback to and from all.
Complete Integration
ILLUMINATOR allows multiple processes to come together in a single integrated workflow tool. These can include processes managed in other systems and if unified with Graphical Data’s RESOLVE software - exceptional end to end project performance improvements can be realised. ILLUMINATOR and its comprehensive toolkit are designed to manage large volumes of complex data. This can include systems procured from scratch, the re-structuring of existing databases, or the unification of data mastered elsewhere in multiple discrete repositories to provide a ‘single view of the truth’, ILLUMINATOR can deliver it all. ILLUMINATOR facilitates exceptional levels of software configuration to meet unique/specific data management requirements but can also realise these very rapidly.
Asset management databases and configuration management databases are numerous. However, ILLUMINATOR’s power is that in addition to these standard functions, it can be configured to be capable of much more. This includes integration of very unique data sets not normally managed in broad enterprise level applications.
';
Vela Luna
';
Vela Encompass
';
Twelve-channel cable/terrestrial receiver for PCIe
- Next generation of the DTA-2139C with added support for ATSC 3.0 and ATSC 1.0 (8VSB). Combinations are supported, too!
- Twelve tuners and demodulators, each tuneable to any frequency in the VHF or UHF band, and each outputting the entire stream.
- Each receiver provides an indication of lock status, RF level and MER for that channel.
- 24/7 continuous compliancy monitoring of an entire cable or terrestrial network, using DekTec Xpect or another monitoring solution.
- Receiving all (or many) services in a free-to-air terrestrial network and remultiplexing them to a cable network.
- Creating a mosaic of all services on a cable or terrestrial network.
';
PacketStormVIP
';
BCi Digital Systems Integration
Comprehensive Systems Integration Support:
Early Stage Consulting
Vendor RFI and RFP Support
Budgeting and Detailed Project Planning
Vendor Selection and Solution Design
System Integration and Test Planning
End-to-End Platform Testing
Operations Transition and Training
';
ControlBridge®
ControlBridge® is a multisystem control platform that allows you to control any KVM, AV or room control system via IP, serial, I/O or relais. The 7/12" tabletop panels provide an elegant one-touch solution for controlling Ethernet-enabled systems in master control rooms or post-production suites. Use the touch panel alone or with a ControlBridge hardware Processor to control devices with I/O interfaces. You can program the panel with the included ControlBridge Builder software or rely on Black Box's programming services.
- Control your AV, KVM, and room automation systems with 7/12" touch panels, desktop and wall panels, and even your smart phone or other mobile device (iOS, Android, Windows).
- Provides bidirectional control of any IP enabled device.
- Active matrix touch-screen display offers resolutions of 1280 x 800 and 32-bit (True Color) images.
- Includes built-in microphone, speakers, and light and motion sensors.
- Set up through a standard web browser.
- A real-time clock enables scheduling applications.
- Access and control equipment a number of ways: via an Ethernet connection, an IR remote, a bidirectional RS-232 serial channels, digital I/O, and a relay connection.
- Black Box will work with you to customize a user interface to meet the needs of your specific application.
';
DataMiner
DataMiner is the most advanced end-to-end multi-vendor NMS, OSS and orchestration software solutions for the broadcast, satellite, cable, telco and mobile industry. The platform offers a plethora of functions including unlimited web access, alarm monitoring, email and SMS notification, long-term trending, professional reporting, advanced automation, intelligent correlation and root cause analysis, service management, real-time SLA monitoring, user-definable key performance indicator dashboards, spectrum monitoring, mobile access, powerful CPE management, inventory and asset management, and much more. One interface to manage your entire operational ecosystem, across any vendor and technology boundaries, results in a significant reduction of operational expenses and increased quality of service. This award-winning solution is integrated with more than 5500 devices and systems from more than 600 different key industry suppliers. It enables end-to-end integration of the most complex technical ecosystems and has been deployed by leading operators around the world.
More info: www.skyline.be / www.dataminer.co
';
