SmallHD FOCUS 7″ Full HD Touchscreen Monitor with Teradek Bolt 500 RX

Create » Content Acquisition and Capture » Camera Accessories » Camera support and grip »

SmallHD FOCUS 7" Full HD Touchscreen Monitor, 1000 nits of Brightness with Teradek Bolt 500 RX integrates Teradek's Bolt 500 wireless receiver with the FOCUS 7 daylight-viewable on-camera monitor. Using the built-in receiver, the FOCUS 7 can receive up to 1080p60 video from Teradek's Bolt 500, Bolt 500 LT or Bolt 500 XT transmitters, or from a SmallHD's FOCUS Bolt 500 TX, with a line-of-sight transmission distance of up to 500'.



The included rubberized handgrips and neck strap enable you to comfortably carry the combo unit around the set. An L-series type battery kit, cable clips, matte and glossy screen protectors, and cleaning cloth are also included. Designed with professional monitoring tools, the SmallHD FOCUS 7" On-Camera Monitor is bright, lightweight, and features a sharp 323 ppi display. The 1000 cd/m² bright touchscreen 1920 x 1200 IPS LCD panel is daylight-viewable and supports up to UHD 4K video via its micro-HDMI input. Using the intuitive Swipe OS, you can turn on and save pages of various monitoring tools and focusing aids with a tap.



At the rear of the monitor, a dual NP-F battery bay enables you to hot-swap L-series batteries with only one required to power the unit. A 3.5mm barrel DC output can power select cameras with a separately available DC coupler, enabling you to extend your DSLR or mirrorless camera's runtime. A tilt arm is included for mounting the monitor via your camera's accessory shoe or on a 1/4"-20 screw.



Features:



Daylight viewable, 7" touchscreen on-camera monitor with 1000 cd/m² brightness



The integrated Teradek Bolt 500 receiver supports up to 1080p60 video; a full-size HDMI input supports up to UHD 4K



Compatible with Bolt 500/500 LT/ 500 XT or Bolt 500 TX transmitter



Up to 500' line-of-sight transmission



Lightweight, compact design, 10-bit IPS LCD panel



Uses SmallHD Swipe OS3 to organize and save customized function and settings pages



Included support arm tilts up to 180° and mounts to either a 1/4"-20 screw or a cold shoe



The dual-battery plate enables you to hot-swap two L-series type batteries for continuous operation







Display Tools:



Pixel Zoom: 2x and 4x with pinch zoom



Aspect Ratios: Preset and customizable



DSLR Scale: Canon 5D Mk II and Canon 7D



Custom Scale: Underscan only



Anamorphic De-Squeeze: 1.33x, 1.5x, 1.66x, 2.0x



Image Flip: Auto and manual



Image Rotation: Auto and manual



Color Focus Assist: Adjustable style and intensity



Peaking: Adjustable intensity



False Color: Spectrum, ARRI-style and customizable



Dual Zebra: Customizable



Waveform: Luma and RGB, customizable with region of interest highlighting



Vectorscope: Yes



Picture-in-Picture: No



RGB Parade: Customizable



Histogram: Luma and RGB



Horizon Indicator: No



Image Capture: With dedicated button and image gallery



Custom LUTs: Load as looks on pages or as system-wide calibration via the settings menu



LUT Import: Via SD card or USB storage device



Image Overlay: Opacity slider and blink setting



Blue Only: No



Audio Meters: Up to 8 channels
